CWDM XFP transceiver series is designed for single-mode fiber serial optical data communications such as 10G Ethernet 10GBASE-ER/EW/ZR and 10G Fiber Channel 1200-SM-LL-L. The 10G CWDM XFP module operates at a nominal wavelength of CWDM wavelength. There are 18 center wavelengths available from 1270 nm to 1610 nm, with each step 20 nm.The transceiver offers optimum heat dissipation, low power consumption and excellent electromagnetic shielding. Our 10G CWDM XFP transceiver modules are designed for 10km, 40km, 80km transmission distance with 1270-1330nm or 1470-1610nm working wavelength.

Performance Feature:

1, Supports 9.95Gb/s to 11.1Gb/s bit rates

2, Hot-pluggable XFP footprint

3, Maximum link length of 10km with SMF

4, 4-Wavelengths Uncooled CWDM DFB laser from1270nm to 1610nm, with Step 20nm

5, XFP MSA package with duplex LC connector

6, No reference clock required

7, Compatible with RoHS

8, +3.3V power supply

9, Power dissipation<2.5W

10, Built-in digital diagnostic functions

11, Temperature range 0°C to 70°C
