Name:SFP Media Converter
Data Rate:Gigabit Ethernet 10/100/1000Base-TX to 1000Base-FX
Fiber Mode:Multimode,Single mode, BiDi
Wavelength:850nm, 1310nm, 1550nm
Fiber Connector:SFP slot
Distance:From 2km to 80km
Transmission Mode:Half duplex or full duplex
Power Supply:External/Internal
Power Adaptor:Euro, American, UK Standard, etc
Optical Function:Supporting the transmission of extra-long VLAN packets

Product Description

10/1001000M SFP slot media converter are effective solution, while uplink interface upgrade or network re-design.

 It can implement date transmission between twisted pair electrical signals and optical signals (SFP module).

Performance Feature:

1, Compliant with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-TX,IEEE 802.3z 1000Base-FX Standards.

2, Provide one 10/100/1000Base-T port with RJ-45 connector, one SFP Slot socket.

3, Full-duplex and half-duplex auto-sensed

4, Supports Auto MDI / MDI-X function

5, Supporting the transmission of extra-long VLAN packets

6, Supporting Quality of Service (QoS) and ensuring the transmission of VoIP packets

7, Supporting STP to form a redundant network

8, Front panel Diagnostic LED Indications



    Network Communication

    FTTH / FTTB / FTTx

    10/100/1000M Ethernet long-distance transmitting network
